Dell Networking N3048P,L3,POE+,48x1GbE,2xCombo,2x10GbE SFP+Fixed Ports,Stacking,IO To PSU Air,1×110

General

• Subtype
  Gigabit Ethernet
• Ports
  48 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x combo 1000Base-T
• Power Over Ethernet (PoE)
  PoE+
• Capacity
  MAC addresses: 16384
  IPv4 routes (static): 1024
  IPv6 routes (static): 1024
  IPv4 routes (dynamic): 8160
  IPv6 routes (dynamic): 4096
  Maximum member ports per LAG: 8
  Maximum dynamic ports per switch stack: 144
  LAG groups: 128
  OSPF routes: 8160
  RIP routes: 512
  ECMP next hops per route: 4
  ECMP groups: 64
  VLAN routing interfaces: 128
  VLANs supported: 4094
  Multicast entries (IPv4): 512
  Multicast entries (IPv6): 256
  ARP entries: 6144
  NDP entries: 400
  ACL: 100
  Maximum rules per ACL: 1023
  Max ACL rules system-wide: 4096
  Maximum ACL rules per interface (IPv4) egress rules: 1024
  Maximum ACL rules per interface (IPv4) ingress rules: 3072
  Maximum ACL rules per interface (IPv6) egress rules: 512
  Maximum ACL rules per interface (IPv6) ingress rules: 1021
  Maximum VLAN interfaces with ACLs applied: 24
• Authentication Method
  RADIUS, Secure Shell (SSH), TACACS+
• MAC Address Table Size
  16K entries
• Authentication Method
  Secure Shell (SSH), RADIUS, TACACS+
• Power Over Ethernet (PoE)
  PoE+
• Encryption Algorithm
  MD5, AES, SSL, TLS
• Routing Protocol
  OSPF, RIP-1, RIP-2, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, OSPFv3, MLDv2, MLD
• Manufacturer
  Dell, Inc.

Camera

• Installed Size
  256 MB

Power Device

• Power Provided
  1100 Watt
• Type
  internal power supply
• Hot-Plug
  hot-plug

Networking

• MAC Address Table Size
  16K entries
• Subcategory
  network hubs and switches
• Subtype
  Gigabit Ethernet
• Form Factor
  rack-mountable
• Type
  Switch
• Stackable
  stackable
• Advanced Switching
  Layer 3
• Features
  Access Control List (ACL) support, Broadcast Storm Control, Dynamic VLAN Support (GVRP), Energy Efficient Ethernet, Generic VLAN Registration Protocol (GVRP), LLDP support, Link Aggregation Control Protocol (LACP), MDI/MDI-X switch, Multiple Spanning Tree Protocol (MSTP) support, Network Access Control (NAC), Per-VLAN Rapid Spanning Tree (PVRST), Protocol-based VLANs support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, STP Root Guard, Weighted Round Robin (WRR) queuing, auto-negotiation, dual firmware images, flow control, layer 2 switching, layer 3 switching, load balancing, port forwarding, port mirroring, redundant fans, stackable, tagged VLAN
• Compliant Standards
  IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
• Ports Qty
  48
• Manageable
  Yes
• Routing Protocol
  IGMP, IGMPv2, IGMPv3, MLD, MLDv2, OSPF, OSPFv3, PIM-DM, PIM-SM, RIP-1, RIP-2, VRRP
• Remote Management Protocol
  HTTP, RMON, SNMP, SNMP 2, SSH
• Power Over Ethernet (PoE)
  PoE+

3Yr ProSupport l: (7×24) 4-hour Onsite Service – Indo, Vn, Ph & Bru
