Dell Networking X1026P Smart Web Managed Switch, 24x 1GbE PoE (up to 12x PoE+) and 2x 1GbE SFP ports

More info (stock and price)?

WA : 0816-7277-73

————————————————————————

Spesifikasi :

Networking – PowerConnect™

Dell Network
Smart Web Managed
Switch

X1000

Dell Networking X1026P Smart Web Managed Switch, 24x 1GbE PoE (up to 12x PoE+) and 2x 1GbE SFP ports

General

Subtype :
Gigabit Ethernet

Ports :
24 x 10/100/1000 + 2 x Gigabit SFP

Power Over Ethernet (PoE) :
PoE+

PoE Budget :
369 Watt

Performance :
Switching fabric bandwidth: 52 Gbps
Forwarding performance: 38.7 Mpps

Capacity :
MAC addresses: 16000
LAG groups: 12
Priority queues per port: 4
Virtual interfaces (VLANs): 4096
Maximum member ports per LAG: 8

Authentication Method :
RADIUS, TACACS+

MAC Address Table Size :
16K entries

Authentication Method :
RADIUS, TACACS+

Power Over Ethernet (PoE) :
PoE+

PoE Budget :
369 W

Manufacturer :
Dell, Inc.

Power Device

Power Provided :
450 Watt

Nominal Voltage :
AC 120/230 V

Frequency Required :
50/60 Hz

Power Consumption Operational :
37 Watt

Type :
internal power supply

Networking

MAC Address Table Size :
16K entries

Subcategory :
network hubs and switches

Subtype :
Gigabit Ethernet

Form Factor :
rack-mountable

Type :
Switch

Advanced Switching :
Layer 2+

Features :
ARP inspection, Access Control List (ACL) support, Back Pressure Support, Broadcast Storm Control, DHCP relay, DHCP server, DHCP snooping, DNS server, GARP VLAN Registration Protocol (GVRP), Head of Line Blocking Prevention, IPv6 support, LLDP support, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Proprietary Protocol Filtering, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, SNMP support, SNMP trap, SNTP support, Spanning Tree Protocol (STP) support, Syslog support, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), VLAN support, Virtual Cable Test (VCT) technology, auto-negotiation, port mirroring, static routing
